Cable gland fast connectors cable gland connector curving wing buckled PG/M

Share to:

Cable gland fast connectors cable gland connector curving wing buckled PG/M

Model:: PG/M

MOQ:: 10000

Payment:: T/T L/C

Brand:: XINDALI

Delivery time:: One week

Start Port:: Shanghai/ningbo

Certification:: ISO9001 RoSH CE UL TUV

SKU:
Availability:


Inquire

Product Description

⊹ They are used as a sealing and termination device to ensure that the characteristics of the enclosure which the cable enters can be maintained adequately.

⊹ Working Conditions:Cable glands are made of various plastics, steel, brass or aluminum. Glands intended to resist dripping water or water pressure will include synthetic rubber or other types of elastomer seals. Certain types of cable glands may also serve to prevent entry of flammable gas into equipment enclosures, for electrical equipment in hazardous areas.

Thread specifications	Metric thread, in line with the eu norms.
Products Material	A.C.E.F part made of nylon PA66 (fire rating UL 94 v - 2), B and D part adopts EPDM weather resistance rubber. All kinds of aperture, material of rubber can accept customization
Product certification	European CE certificate,European environmentalROHS, REACH certificate,The United States UL certification, and explosion-proof certification of the EX.
Protection Level	Within the scope of the provisions of card buckle, and use of type O sealing screw tight tight head, achieve IP68-5 bar.
Color type	Black, grey, blue, red, white, add letters after all sorts of color please contact with the product. For example: MA12-08 b black and so on.
Working temperature	Static: - 40 ℃ ~ + 100 ℃ short time can be up to + 120 ℃.
Product features	Special clamping claw, and the design of the clamping ring is concave and convex clasped with forced tight head assembly time-savers, cable clamping range is big, strong tensile resistance, can waterproof, dustproof, salt resistance, resistance to acid and alkali, alcohol, grease and common solvent.
