◆ Characteristic: high light transmission,wear resistance long service life,clear,bright and intuitive
◆Product Features: Accurate Reading/Durable in Use/Energy Conservation/High Brightness Digital Displa
◆ Product material: it is possible to meet all kinds of international srandard Lampshade,which is made of polycarbonate with high intension and enjoying better anti-surge performance,and bolt-type connector designed will make it safer and more convenient.All improvement will be provided to make your choice more convenient and your design perfect.
Applicable environment
Surrounding temperature
-25℃~+55℃
Relative humidity
≤98%
It can normally work under the conditions of2-80Hz vibration frequency and 0.7g/h accelerated speed
Pollution grade：Ⅲ
Indtalled sort：Ⅲ
It is possible to work under the moist tropical environment if there is a“TH” sign
Main technical target
Voltage of working frequency
2.5kV(AC valid value），1min
Insulated resistance
1mΩ
Voltage wave allowed byAC indicator ±20%
Continual working life
≥30000h
Brightness
60cd/m2
Index of leakage CT1
≥100
Protection grade is IP40，and it is possible to be made to up to IP67
Using frequency
AC50-60Hz
Product Details
Product Application
Product Description
◆ Characteristic: high light transmission,wear resistance long service life,clear,bright and intuitive
◆Product Features: Accurate Reading/Durable in Use/Energy Conservation/High Brightness Digital Displa
◆ Product material: it is possible to meet all kinds of international srandard Lampshade,which is made of polycarbonate with high intension and enjoying better anti-surge performance,and bolt-type connector designed will make it safer and more convenient.All improvement will be provided to make your choice more convenient and your design perfect.
Applicable environment
Surrounding temperature
-25℃~+55℃
Relative humidity
≤98%
It can normally work under the conditions of2-80Hz vibration frequency and 0.7g/h accelerated speed
Pollution grade：Ⅲ
Indtalled sort：Ⅲ
It is possible to work under the moist tropical environment if there is a“TH” sign
Main technical target
Voltage of working frequency
2.5kV(AC valid value），1min
Insulated resistance
1mΩ
Voltage wave allowed byAC indicator ±20%
Continual working life
≥30000h
Brightness
60cd/m2
Index of leakage CT1
≥100
Protection grade is IP40，and it is possible to be made to up to IP67
{"type":"1","json":[{"downloadUrl":"//jjrorwxhnnnlli5p.ldycdn.com/AD22+Lndicator+Lamp+Series+P2-12-aidlmBprKjpllSRqjoonmkjjq.pdf?dp=1","encodeFileId":"dLpAKhRfrEIZ","fileId":2702484,"fileName":"AD22 Lndicator Lamp Series P2-12.pdf","fileType":"pdf","photoUrlNormal":"//iirorwxhnnnlli5p.ldycdn.com/static/assets/widget/images/downloadNew/pdf.svg","pname":"AD22 Lndicator Lamp Series P2-12.pdf","name":"AD22 Lndicator Lamp Series P2-12.pdf"}]}
If you have a special product or cannot find the Model Number, you can use the contact form to send us an enquiry. We will get back to you as soon as possible!
